Heat Shrink Tunnel T-450 | 4-GPVT-450 Single Chamber Heat Tunnel

Italian made shrink tunnel - Single Heat Chamber


Heat Shrink Tunnel - 4-GPVT-450 | T-450

This Italian made heat shrink tunnel works with PVC, Polyolefin and Polythylene shrink films and complements a wide range of sealing equipment such as sleeve wrappers or L-Bar Sealers including automatic machines.This single chamber shrink tunnel is equipped with an alphanumeric LCD control panel provided with a 16-bit micro-processor card. It allows a simple and precise control of all the machine operations such as adjustment of the tunnel conveyor speed from at 1% = 2.8m/min  and 100% is 9.4m/min and adjustment of the tunnel shrinking temperature from 85°c – 200°c.  It allows the possibility of scheduling up to 10 different work cycles.

HEAT SHRINK TUNNEL GPVT450 - 3 Phase, 415V

Go to the More Information Tab to vie the brochure.

 USE AND MAINTENANCE MANUAL - 4-GPVT-450

                                  HEAT SHRINK TUNNEL



  • Machine size (LxWxH):  1310mm x 835mm x 1400mm
  •       Max. pack size (WxH): 410mm x 230mm.
  • Machine weight: 187kg.
  • Power supply: 415v 3ph 50Hz.
  • Adjustable speed conveyor.
  • Adjustable air flow.
  • Automatic turn-off.
  • 12 month warranty.
